- 16 -
2.4.2 Outdoor Unit Data – Models CU600, CU700, CU800
Model CU600 CU700 CU800
Casing color RAL 7032 RAL 7032 RAL 7032
Dimensions (LxDxH) mm 1650x500x730 1650x500x730 1650x500x830
m
3
/h 8500 10200 11900
Air flow (at high speed)
cfm 5000 6000 7000
Noise Level (see note 1) dbA 52 54 54
Fittings Type Flare Flare Flare
Expansion Device Capillary tube or expansion valve
Axial Fan Diameter/No. mm 500/2 550/2 550/2
Outdoor Fan Motor KW 0.15 0.37 0.37
Motor Capacitor µF/Volt 5/400 10/400 10/400
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 0.85/9.18 0.85/9.18 0.98/10.58
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 3 4 4
Coil
Fins Spacing Per Inch 12 12
12
Net Weight Kg. 150 163 188
Notes:
1. Noise level measured at a 4 m. distance in free field.
