CU150, CU200, CU200 (Outdoor Unit Refrigerant System Components)
Parts No.
CU250 CU200
CU150
Part Description
No. in
Figure
0601323A 0601243A 060119QA Compressor 1b
0602C34P 0602C24P 0602C18P Compressor1b
11019344 11019344 11019344 4 Way Solenoid Valve 4
1103MF02 1103MF02 1103MF02 Muffler 8
14020001 14020001 14020001 Refrigerant Filling Valve 9
1106BG58 1106BG58 1106BG12 3 Way Service Valve 10
1106BG38 1106BG38 1106BG38 3 Way Service Valve 11
05010031 05010031 05010022 Condenser Heat Exchanger 12b
CU300, CU350, CU400 (Outdoor Unit Refrigerant System Components)
Parts No.
CU400 CU350
CU300
Part Description
No. in
Figure
0601463A 0601423A 060135UA Compressor 1b
0601463D 0601423D 0601354D Compressor 3Ph1b
0602C47P 0602C42P 0602C38P Compressor1b
0602C47T 0602C42T 0602C38T Compressor 3Ph1b
11010946 11010945 11010945 4 Way Solenoid Valve 4
1104HGB1 1104HGB1 1104HGB1 Hot Gas Bypass 6
1105DA53 1105DA53 1105DA53 Suction Controlling Pressure Switch 7
1103MF03 1103MF02 1103MF02 Muffler 8
14020001 14020001 14020001 Refrigerant Filling Valve 9
1106BG34 1106BG58 1106BG58 3 Way Service Valve 10
1106BG12 1106BG38 1106BG38 3 Way Service Valve 11
050100XX 05010035 05010035 Condenser Heat Exchanger 12b
CU450, CU480, CU500(Outdoor Unit Refrigerant System Components)
Parts No.
CU500 CUC480
CU450
Part Description
No. in
Figure
0601623D 0601583D 060543D Compressor 1b
0602500T 0602C450T 0602C53T Compressor1b
11020034 11020034 11020034 Suction Accumulator 2
11012046 11012046 11012046 4 Way Solenoid Valve 4
1104HGB1 1104HGB1 1104HGB1 Hot Gas Bypass 6
1105DA53 1105DA53 1105DA53 Suction Controlling Pressure Switch 7
1103MF03 1103MF03 1103MF03 Muffler 8
14020001 14020001 14020001 Refrigerant Filling Valve 9
1106BG34 1106BG34 1106BG34 3 Way Service Valve 10
1106BG12 1106BG12 1106BG12 3 Way Service Valve 11
050100XX 05010033 050100XX Condenser Heat Exchanger 12b
