- 77 -
CU600, CU700, CU800 (Outdoor Unit Refrigerant System Components)
Parts No.
CU800 CU700
CU600
Part Description
No. in
Figure
N/A 0601943D 0601723D Compressor 1c
0602Z108 0602ZR94 0602ZR72 Compressor1c
06011004 0604M100 0604MT80 Compressor1b
11020078 11020078 11020078 Suction Accumulator 2
11012047 11012047 11012047 4 Way Solenoid Valve 4
1104T075 1104T006 1104T006 Thermal expansion valve 5
1104HGB1 1104HGB1 1104HGB1 Hot Gas Bypass 6
1105DA53 1105DA53 1105DA53 Suction Controlling Pressure Switch 7
1103MF03 1103MF03 1103MF03 Muffler 8
140200001 140200001 140200001 Refrigerant Filling Valve 9
1106BG78 1106BG78 1106BG78 3 Way Service Valve 10
1106BG12 1106BG12 1106BG12 3 Way Service Valve 11
050104D9 05010454 05010036 Condenser Heat Exchanger 12b
CU1000, CU1200, CU1400 (Outdoor Unit Refrigerant System Components)
Parts No.
CU1400 CU1200
CU1000
Part Description
No. in
Figure
0602ZR19 0604M160 0604M125 Compressor 1a
11020118 11020078 11020078 Suction Accumulator 2
PCUC100020 PCUC100020 PCUC100020 Suction Accumulator Support 3
11014518 11013567 11013567 4 Way Solenoid Valve 4
1104T125 1104T075 1104T075 Thermal expansion valve 5
1104HGB3 1104HGB2 1104HGB1 Hot Gas Bypass 6
1105DA53 1105DA53 1105DA53 Suction Controlling Pressure Switch 7
1103MF04 1103MF04 1103MF03 Muffler 8
14020001 14020001 14020001 Refrigerant Filling Valve 9
N/A 1106P118 1106BG78 3 Way Service Valve 10
N/A 1106BG58 1106BG12 3 Way Service Valve 11
050104EO 05010312 05010028 Condenser Heat Exchanger 12b
