Unique CU Series - Page 88

- 82 -
Indoor Unit Assembly Parts
Part No.
CU250-C CU250-A CU200-C CU200-A CU150-C CU150-A
Qty.
Per
Unit
Part Description
No.
in
Fig.
N/A 401M220 N/A 401M220 N/A 401M175
Centrifugal Fan –
Impeller (CU -A)
1
N/A 401B220 N/A 401B220 N/A 401B176
Centrifugal Fan –
Casing (CU -A)
2
4021100 N/A 4021100 N/A 4022691 N/A
Centrifugal Fan –
Right (CU -C)
3
4021101 N/A 4021101 N/A 4022696 N/A
Centrifugal Fan –
Left (CU -C)
4
1106MF38 1106MF38 1106MF38 1106MF38 1106MF38 1106MF38 Fitting – Flare 5
1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 Fitting – Flare 6
100955B22 100955B22 100955B22 100955B22 100955B22 100955B22 Plastic Joint 7
13010043 13010043 13010043 13010043 13010043 13010043
Plastic Fastening
Screw
8
15050001 15050001 15050001 15050001 15050001 15050001 plastic handle 9
15040065 15040064 15044465 15044464 15040061 15040060 Duralast filter 1/2" 10
5010441 5010432 5010441 5010432 5010428 5010485
Evaporator Heat
Exchanger
11
10050070 10050070 10050070 10050070 10050070 10050070
Fan Connector
Cable
12
904T511 904T511 904T511 904T511 904T511 904T511
Indoor Unit Coil
Sensor Cable
13
Indoor Unit Assembly Parts
Part No.
CU400-C CU400-A CU350-C CU350-A CU300-C CU300-A
Qty.
Per
Unit
Part Description
No.
in
Fig.
N/A 4022691 N/A 401M7x7 N/A 401M7x7
Centrifugal Fan –
Impeller (CU -A)
1
N/A 4022696 N/A 401B7x7 N/A 401B7x7
Centrifugal Fan –
Casing (CU -A)
2
4021104 N/A 4021100 N/A 4021100 N/A
Centrifugal Fan –
Right (CU -C)
3
4021105 N/A 4021101 N/A 4021101 N/A
Centrifugal Fan –
Left (CU -C)
4
1106MF12 1106MF12 1106MF38 1106MF38 1106MF38 1106MF38 Fitting – Flare 5
1106MF34 1106MF34 1106MF58 1106MF58 1106MF58 1106MF58 Fitting – Flare 6
100953822 100953822 100953822 100953822 100953822 100953822 Plastic Joint 7
13010043 13010043 13010043 13010043 13010043 13010043
Plastic Fastening
Screw
8
15050001 15050001 15050001 15050001 15050001 15050001 plastic handle 9
15040073 15040072 15040069 15040068 15040069 15040068 Duralast filter 1/2" 10
5010424 5010427 5010413 5010455 5010413 5010455
Evaporator Heat
Exchanger
11
1050070 1050070 1050070 1050070 1050070 1050070
Fan Connector
Cable
12
904T511 904T511 904T511 904T511 904T511 904T511
Indoor Unit Coil
Sensor Cable
13
