Unique CU Series - Page 89

- 83 -
Indoor Unit Assembly Parts
Part No.
CU500-C CU500-A CU480-C CU480-A CU450-C CU450-A
Qty.
Per
Unit
Part Description
No.
in
Fig.
N/A 4022582 N/A 4022691 N/A 4022691
Centrifugal Fan –
Right (CU -A)
1
N/A 4022584 N/A 4022696 N/A 4022696
Centrifugal Fan –
Left (CU -A)
2
4021118 N/A 4021106 N/A 4021104 N/A
Centrifugal Fan –
Right (CU -C)
3
4021119 N/A 4021107 N/A 4021105 N/A
Centrifugal Fan –
Left (CU -C)
4
1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 Fitting – Flare 5
1106MF78 1106MF78 1106MF34 1106MF34 1106MF34 1106MF34 Fitting – Flare 6
100955B22 100955B22 100955B22 100955B22 100955B22 100955B22 Plastic Joint 7
13010043 13010043 13010043 13010043 13010043 13010043
Plastic Fastening
Screw
8
15010001 15010001 15010001 15010001 15010001 15010001 plastic handle 9
1505001 1505001 1505001 15040072 15040076 15040072 Duralast filter 1/2"10
15040083 15040082 15040079 5010510 5010414 5010427
Evaporator Heat
Exchanger
11
10050070 10050070 10050070 10050070 10050070 10050070
Fan Connector
Cable
12
904TS11 904TS11 904TS11 904TS11 904TS11 904TS11
Indoor Unit Coil
Sensor Cable
13
Indoor Unit Assembly Parts
Part No.
CU800-C CU800-A CU700-C CU700-A CU600-C CU600-A
Qty.
Per
Unit
Part Description
No.
in
Fig.
N/A 4021104 N/A 4021101 N/A 4021100
Centrifugal Fan –
Right (CU -A)
1
N/A 4021105 N/A 4021105 N/A 4021101
Centrifugal Fan –
Left (CU -A)
2
4021120 N/A 4021120 N/A 4021118 N/A
Centrifugal Fan –
Right (CU -C)
3
4021121 N/A 4021121 N/A 4021119 N/A
Centrifugal Fan –
Left (CU -C)
4
1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 1106MF12 Fitting – Flare 5
1106MF78 1106MF78 1106MF78 1106MF78 1106MF78 1106MF78 Fitting – Flare 6
110955B22 110955B22 110955B22 110955B22 110955B22 110955B22 Plastic Joint 7
13010043 13010043 13010043 13010043 13010043 13010043
Plastic Fastening
Screw
8
15050001 15050001 15050001 15050001 15050001 15050001 plastic handle 9
15040095 15040094 15040091 15040090 15040087 15040086 Duralast filter 1/2" 10
50104E5 50104E6 5010471 5010472 5010423 5010473
Evaporator Heat
Exchanger
11
10050070 10050070 10050070 10050070 10050070 10050070
Fan Connector
Cable
12
904TS11 904TS11 904TS11 904TS11 904TS11 904TS11
Indoor Unit Coil
Sensor Cable
13
