Indoor Unit Assembly Parts
Part No.
CU1400-A CU1200-A CU1000-C CU1000-A
Qty.
Per
Unit
Part Description
No.
in
Fig.
4021120 4021138 N/A 4021108 1
Centrifugal Fan –
Right (CU -A)
1
4021120 4021138 N/A 4021109 1
Centrifugal Fan –
Left (CU -A)
2
N/A N/A 4021120 N/A
Centrifugal Fan –
Right (CU -C)
3
N/A N/A 4021120 N/A
Centrifugal Fan –
Left (CU -C)
4
1106MF78 1106MF58 1106MF12 1106MF12 1 Fitting – Flare 5
N/A N/A 1106MF78 1106MF78 1 Fitting – Flare 6
1009SB22 1009SB22 1009SB22 1009SB22 1 Plastic Joint 7
13010043 13010043 13010043 13010043 4
Plastic Fastening
Screw
8
15050001 15050001 15050001 15050001 2 plastic handle 9
15040053 15040052 15040050 15040051 1 Duralast filter 1/2" 10
50104E8 5010486 50104C8 5010489 1
Evaporator Heat
Exchanger
11
10050071 10050071 10050071 10050071 1
Fan Connector
Cable
12
904TS11 1005T002 1005T002 1005T002 1
Indoor Unit Coil
Sensor Cable
13
