30
Copyright 2014 unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of unitech Electronics Co., Ltd.
In the example below, the white box is the centering window. The centering window has been
set to 20% left, 30% right, 8% top, and 25% bottom. Since Bar Code 1 passes through the
centering window, it will be read. Bar Code 2 does not pass through the centering window, so it
will not be read.
Note: A bar code needs only to be touched by the centering window in order to be read. It does
not need to pass completely through the centering window.
