3.1.11 Wrist 1 joint – Lower arm

Disassemble

For details and photos please see: 3.1.4 General guidance to separate joint from counterpart Shut down

the controller.

1. Remove blue lid on Wrist 1 joint.

2. Connect ESD wristband

3. Disconnect wires between lower arm and Wrist 1 joint.

1 x red wire = 48V DC

1 x black wire = GND

Black connector = bus cable (NB: polarized)

4. Remove alignment screw.

5. Gently remove black flexible gasket between lower arm and Wrist 1 joint with a tiny screwdriver or

similar tool and twist it around the lower arm.

6. 10 screws become visible, 5 on each side of joint. Loosen the screws with a 5.5 mm. open-ended

spanner about two full turns, approximately 3 mm. for each screw.

7. Pull the lower arm and Wrist 1 joint apart and gently twist the two parts in opposite directions around

8 mm. until a mechanical stop is met (holes are keyhole-type).

8. Pull away the lower arm from Wrist 1 joint.
