2.2 Robot arm

2.2.1 Visual inspection

 If you observe dirt/oil on the robot arm you simply clean it with a soft cloth.

Cleaning agent: Water, Isopropyl alcohol, 10% Ethanol alcohol or 10% Naphtha

In very rare cases the grease is from the inside of the joint. There is still enough grease in the gear

for life time you just clean the joint with a cloth.

 Move robot arm to HOME position (if possible)

 Turn off and disconnect power cable from controller

 Inspect cable between controller and robot arm for any damage

 Inspect flat rings for wear and damage

» Replace flat rings if worn out or damaged

 Inspect blue lids on all joints for any cracks or damage

» Replace blue lids if cracked or damaged.

 Inspect that screws for blue lids are in place and properly tightened

» Replace screws, tighten properly if necessary

Correct torque value for screws on blue lids are 0.4Nm

If any damage is observed on a robot within the warranty period, contact the distributor from which the

robot has been purchased.
