All rights reserved 76 Servicemanual_UR10_en_3.1.3
Powersupply voltage too low
Powersupply voltage too high
Voltage not detected at 24V
rail after startup
24 V to the I/O interface in the
controller
Warning, waiting for
SafetySYS2
SafetySYS2 = Processor B on
Safety Control Board
The Teach Pendant does not
respond
Loose wire or incorrect safety
configuration. Message comes
from Safety Control Board
Check the cable or change
in the Safety Configuration
of the Installation the
miscellaneous settings
The Euromap67 interface does
not respond
Loose wire or incorrect safety
configuration
Check the cable or change
in the Safety Configuration
of the Installation the
miscellaneous settings
Warning, waiting for
SafetySYS1
SafetySYS1 = Processor A on
Safety Control Board
5V, 3V3 or ADC error (5V too
high)
5V, 3V3 or ADC error (5V too
low)
Robot current sensor reading
too high
Robot current sensor reading
too low
48V not present (Check
internal connection)
This error can have several root causes and you have to measure the voltage some places.
There are 3 different components that could be the root cause and you have to measure the
voltage to determine which one of them that is the faulty one.
- 48 V power supply
- Current distributor
- Safety Control Board.
Find the schematic drawing in this service manual
Robot voltage present at 48V
PSU powereup
Voltage present on unpowered
48V power supply
12V, 3V3 or ADC error (12V
too high)
12V, 3V3 or ADC error (12V
too low)
Analog I/O error (-12V too
high)
Analog I/O error (-12V too
low)
The other safetySYS do not
initialize
Voltage will not disappear
from PSU
