Description Blending enables the robot to smoothly transition between two trajectories, without
stopping at the waypoint between them.
Blending makes your robot program run faster because, when you create a smooth
transition between trajectories, you avoid slowing down an acceleration between
trajectories.
Blend
parameters
Apart from the waypoints, multiple parameters will influence the blend trajectory.
•
the blend radius (r)
•
the initial and final speed of the robot (at positions p1 and p2 , respectively)
•
the movement time (e.g. if setting a specific time for a trajectory this will influence
the initial/final speed of the robot)
•
the trajectory types to blend from and to (MoveL, MoveJ)
r
WP_1
WP_2
WP_3
p1
p2
O
31.2: Blend over (WP_2) with radius (r) , initial blend position at p1 and final blend
position at p2 . (O) is an obstacle.
