8.2.2.5 Multi display
Select this option to activate multi display mode and extrapolate a zone from the displayed image to be followed more in
detail.
The following screen will appear when this option is selected:
Figure 94: multi display interface
Multi display mode can be activated either during playback or still.
Procedure for activating multi display mode during playback
Click on “Set”.
Define the zoom level and the zone to be viewed in detail with the mouse (click and drag). The concerned zone
will be enclosed in a green rectangle. Coordinates will be automatically updated.
Procedure for activating multi display mode during still
Define the zoom level and the zone to be viewed in detail with the mouse (click and drag). The concerned zone
will be enclosed in a green rectangle. Coordinates will be automatically updated.
8.2.3 CONTROL (C)
The “FILE” menu includes the following items:
8.2.3.1 Play/Pause
This plays/stops the selected video.
8.2.3.2 Stop
This stops the video being played.
8.2.3.3 Step Forward
This function can be used to play the images at various speeds. Press repeatedly to change the speed.
8.2.3.4 Step Backward
Reduces playback speed at a frame rate slower than 25fps.
8.2.3.5 Goto Start
Point indicator to start of playback.
8.2.3.6 Goto End
Point indicator to end of playback.
8.2.3.7 Locate To
Select this option to determine the point from where to start playback according to the following search criteria:
frame
elapsed time
DS1093-005C 117
