6.3 PLAYING A RECORDING
After setting the search parameters (event type, date/time, main and secondary channel) and starting search by pressing
the “SEARCH” button, select the file to be played from the hit list and press “ENTER” to start playback.
The monitor will appear as below if two video channels are played:
Figure 59: synchronous playback of 2 video channels
The control interface shown below appears in the lower part of the screen:
; 50% 1x 00:25:30/00:50:15 Press EDIT to start copying
Total playback time
Elapsed time
Playback speed
Playback advancement percentage
Playback with audio (with 1093/041 only)
Press “ENTER” to stop playback.
Press “ENTER” to resume playback.
Press “▲” repeatedly to increase the playback speed with respect to normal speed (1x). Several speeds are available.
Press “▼” repeatedly to decrease the playback speed with respect to normal speed (1x). Several speeds are available.
Select “Single” to play one frame at a time and press “ENTER”.
If two video channels are being played at the same time (main and secondary), press “PREV” repeatedly to change the
display on the monitor: the main channels will be shown on full screen followed by the secondary channel selected
above.
Press “PLAY” to mute the audio (function available only on devices provided with audio function 1093/041).
Press “MENU” to show or hide the command interface bar.
Press “ESC” to quit playback mode.
6.3.1 PLAY
Select “Play” to start playback without interruption of recordings according to the set search parameters. Playback will
stop when the end of the last recording on the last page of the list box is reached.
DS1093-005C 80
