7.4.8.2 Live (Play)
Click on
to access the LIVE interface.
The following screen will appear.
Figure 67: LIVE interface
This interface may be used to:
select the preferred viewing mode
stop/start all available video channel connections
stop/start single video channel connection
acquire a snapshot of the selected LIVE video channel (red box).
start/stop recording of the selected LIVE video channel (red box).
establish a two-way voice connection with the connected DVR (function available on 1093/040-041-045 only)
manage volume, brightness, contrast, hue and colour parameters for each of the connected video channels
manage PTZ cameras using the PTZ interface.
eIMPORTANT NOTE
The selected video channel is the one with the red box in the view grid not the one shown in the channel status interface.
Figure 68: selected channel
Selected video
channel (red box)
Highlighted video
channel
DS1093-005C 92
