vacon • 118 Appendices
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Figure 86. Dimensions of the door mounting kit
23
152
144
Dia 4, 5-5 mm, Screw M4
114.5
14.5
0
23
125 115 107.5
11214.emf
7.5
0
10
