Vaisala HUMICAP HMT310 - Hmt314; Hmt315; Figure 22 HMT314 Dimensions; Figure 23 HMT315 Dimensions

Chapter 8 ____________________________________________________________ Technical Data
VAISALA_______________________________________________________________________ 79
HMT314
0507-052
Figure 22 HMT314 Dimensions
HMT315
*)
12 (0.47)
13.5 (0.5
3
41 (1.61)
242 (9.53)
192 (7.56)
75 (2.95)
28 (1.10)
27
(1.06)
2 (0.08)
0507-053
Figure 23 HMT315 Dimensions
*) Flange for HMT315 available as an option
