Appendix A ___________________ PROBE INSTALLATION KITS AND INSTALLATION EXAMPLES
VAISALA_______________________________________________________________________ 83
Examples of Vapor-Tight Installations with
Cable Gland
RH Probe Installations (for HMT313/317)
1
3
2
0508-026
Figure 28 Cable Installation with Cable Gland AGRO
The following numbers refer to Figure 28 above:
1 =
Nut (to be tightened to the body)
2 = Seal
3 = Body and O-ring
Vaisala order code for the cable gland: HMP247CG (see Options and
Accessories on page 76).
