• For dimensions and weight see Technical specifications.
• Before calibration make sure that the cable between sensor and TCU is properly
connected; this cable contains the optical fiber.
Installing the TCU
The TCU uses a hazardous voltage. Only a qualified electrician may connect the TCU.
Make sure to connect the earth correctly, double-check after connecting.
DANGER:
High voltage inside the TCU!
Safety recommendations | 11 (48)
K20798 V1.1 EN - 1 - 12/2019
