5 Installing the sensor
5.1 Sensor dimensions
Before starting the installation, make sure that the sensor fits properly in the selected
installation site. Measured from the pipe surface, there must be at least 500 mm (~ 20")
of free space to allow the installation of the sensor. Make sure to leave sufficient room
around the sensor to perform this task.
Dimensions, OC2R Dimensions, process coupling
Installing the sensor | 12 (48)
K20798 V1.1 EN - 1 - 12/2019
