8.2 Result displays
Main result display:
• Tag: Device "tag" or position code in
the system. This can be changed in
Configuration > User settings.
• Recipe1: Currently selected recipe. This can be changed in Configuration >
Recipe selection. Letter "R" after the number indicates that remote recipe
selection is in use. In this case the active recipe is selected by two digital input
signals on the TCU unit.
• Cs: Consistency in percentage points (% Cs).
• Ash: Ash consistency, percentage.
• Elec.T: Electronics temperature (C).
• Status: Device status information (OK / alarm / error message).
Extra result displays:
•
mA PV/SV: Analog output values in
milliamps (mA).
• Elec.T: Device electronics tempera-
ture.
Operating | 27 (48)
K20798 V1.1 EN - 1 - 12/2019
