4. Open the ball valve and push the sen-
sor probe through the ball valve.
5. Screw down the sealing nut to the
sealing bushing and tighten it.
Note:
Before calibration, ensure that the optical fiber cable between probe
and TCU is properly connected and fastened, for example secured to a
cable rack with cable ties.
Installing the sensor | 20 (48)
K20798 V1.1 EN - 1 - 12/2019
