55
Fuel BedsInstallation
2. Place rear log H62 behind H37; bring log forward to
rest it on both sides against the raised part of the
rear ceramic plate pieces.
3. Place H63 resting its front end in the recess in the
front ceramic plaque and its other end on H62’s left
side fl at part.
H62
H37
H63
H62
4. Place H64 resting its front end in the recess in the
front ceramic plaque and its other end on H62’s
right side fl at part.
5. Place H60 in front of H37, in the recess of the
ceramic plaque.
H64
H62
H60
H37
