Fuel BedsInstallation
6. Place the wider part of H65 on the fl at notched part
of H63 then rest the narrow end on ceramic plaque
between H37 and H60.
H65
H63
H65
H37
H60
H63
7. Place the wider part of H61 in the recess on the
ceramic plaque’s front and rest its narrower end on
H62.
8. Add pebbles on the ceramic plaques as desired to
complete the installation. Do not place pebbles on
the burner!
H61
H62
1400DWKV2 Driftwood installed
H60
H62
H63
H64
H65
H61
H37
