Valor H6 - Page 86

86
Appendix D - HeatShift System
Plenum Dimensions
48” LDK 1
LDK 1
5” dia.
collars (4)
C
L
12” LDK 1 14” LDK 1 12” LDK 1
2”
8”
1/2”
standos
6” openings
each end for
optional
1270RBK
connection
11-1/2”
8”4”
1/2” wallboard
mounting
bracket and
1-1/2” stando
mounting
bracket and
1/2” stando
3”
1/2”
stando
3-5/8”
7-7/8”
11-1/2”
Top View
Front View Right Side View
LDK 4
38” LDK 4
5” dia.
collars (4)
C
L
8” 14” 8”
4”
4”
3”
3-5/8”
7-7/8”
11-1/2”
1/2”
stando
Front View
Top View
2”
8”
1/2”
standos
6” openings
each end for
optional
1270RBK
connection
11-1/2”
8”4”
1/2” wallboard
mounting
bracket and
1-1/2” stando
mounting
bracket and
1/2” stando
Right Side View
