Valor H6 - Page 87

87
Appendix D - HeatShift System
LDK 9
30” LDK 9
5” dia.
collars (4)
C
L
7-1/16” 7-1/16” 7-1/16” 4-3/8”
4-3/8”
3”
9-1/2”
Front View
Top View
2”
6”
9-1/2”
6”4”
1/2” wallboard
mounting
bracket and
1-1/2” stando
mounting
bracket and
1/2” stando
Right Side View
6-1/2”
3”
Plenum Dimensions (cont’d)
LDK 3
14”
C
L
7”
6”
5” dia.
collars (2)
3”
mounting
bracket and
1-1/2” stando
mounting
bracket and
1/2” stando
8”
11-1/2”
1/2” wallboard
1/2”
standos
Front View Right Side View
1/2”
stando
