Shot settings
Parameter Value Unit Default Description
DeadT 0.02 … 300.00 s 5.00
The dead time setting for this
shot. This is a common setting
for all the AR lines in this shot
AR1 On; Off - Off
Indicates if this AR signal
starts this shot
AR2 On; Off - Off
Indicates if this AR signal
starts this shot
AR3 On; Off - Off
Indicates if this AR signal
starts this shot
AR4 On; Off - Off
Indicates if this AR signal
starts this shot
Start1 0.02 … 300.00 s 0.02
AR1 Start delay setting for this
shot
Start2 0.02 … 300.00 s 0.02
AR2 Start delay setting for this
shot
Start3 0.02 … 300.00 s 0.02
AR3 Start delay setting for this
shot
Start4 0.02 … 300.00 s 0.02
AR4 Start delay setting for this
shot
Discr1 0.02 … 300.00 s 0.02
AR1 Discrimination time
setting for this shot
Discr2 0.02 … 300.00 s 0.02
AR2 Discrimination time
setting for this shot
Discr3 0.02 … 300.00 s 0.02
AR3 Discrimination time
setting for this shot
Discr4 0.02 … 300.00 s 0.02
AR4 Discrimination time
setting for this shot
Measured and recorded values of AR function:
Parameter Value Unit Description
Obj1 UNDEFINED;
OPEN;
CLOSE;
OPEN_REQUEST;
CLOSE_REQUEST;
READY;
NOT_READY;
INFO_NOT_AVAILABLE;
FAIL
-
Object 1
state
Measured
or
recorded
values
Status INIT;
RECLAIM_TIME;
READY;
WAIT_CB_OPEN;
WAIT_CB_CLOSE;
DISCRIMINATION_TIME;
LOCKED;
FINAL_TRIP;
CB_FAIL;
INHIBIT
-
AR-function
state
