AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 9: ILLUSTRATED PARTS LIST
090019-OP_r0 PAGE - 125
9.5 INSTRUMENT PANEL
ITEM DESCRIPTION PART NUMBER QTY
1 ELBOW, 1/4T x 1/8P PUSH-ON 261309 1
2 ELBOW, 90 DEG. PUSH ON 1/4T x 1/4P 261310 1
3 WASHER, NYLON 5/16-18 262943 4
4 WASHER, FLAT REDUCING 3/4 x 1 ELECT. 267994 2
5 RECEPTACLE, 120V/20A 270092 1
6 COUPLING, PIPE 1/8 806230-005 1
7 PLUG, PIPE 1/2 807800-020 2
8 NUT, HEX #10-24 825202-130 2
9 NUT, HEX 1/4-20 825204-226 2
10 NUT, HEX FLANGE 1/4-20 825304-236 4
11 CAPSCREW, HEX GR5 1/4-20 x 1 1/2 LG. 829104-150 2
12
I
CAPSCREW, HEX GR8 1/4-20 x 3/4 LG 829404-075 6
13
I
SCREW, SER WASH 5/16-18 x 0.75 829705-075 2
14 WASHER, FLAT 1/4 838204-071 2
15 WASHER, LOCK 1/4 838504-062 8
16 ELBOW, 37FL/90M #08 x 1/2 860208-050 1
17 FACEPLATE, CONTROL PANEL A1269483 1
18 PANEL, CONTROL BACK A1269489 1
19 CLAMP, CONTROL PANEL CABLE A1269491 1
20 COVER, CONTROL PANEL CABLES A1269492 1
21 MODULE, WELD CONTROL SYS ASSY CO269598 1
22 SWITCH, IGNITION EFI ENGINES CO269713 1
23 GAUGE, FUEL / HOUR METER CO269748 1
24
II
SENSOR, HALL EFFECT WELD CONTROLS CO269900 1
25 PANELMETER, VOLTAGE, LED CO270314 1
26 KNOB, PLASTIC, 1.3 DIA., 1/4 SHAFT CO59489 1
27 LAMP, INDICATOR, LED, GREEN CO59966 5
28 CIRCUIT BREAKER, 20 AMP CO62617 2
Continued on page 127
I
Toggle switches and potentiometer are included with harness EP269872; wiring instrument panel switches.
II
Refer to inset AA.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER.
