Vanair 050817 - SECTION 5: OPERATION; Engine Start-up and Shutdown Procedure

AIR N ARC
®
200 SERIES ALL-IN-ONE POWER SYSTEM
®
SECTION 3: SPECIFICATIONS
090019-OP_r0 PAGE - 33
TABLE 3E: VARIOUS FUNCTION ACCEPTABLE TESTING OUTPUT RANGES
FUNCTION ACCEPTABLE RANGE
Engine No-Load Hi RPM 3660 +/-10
Engine Idle RPM
2000 +/-10
Air Cut-in Pressure
150 +/-10
Air Cut-out Pressure
175 +/-10
AC Generator Hz (no load) 61+/-1
AC Generator 240 Plug
243 +/-3
AC Generator 120 Plug
122 +/-2
AC Generator 120 Plug
122 +/-2
Welder Max Voltage 70 +/-10
Welder Max Amperage
300 +/-5
Welder Max CV Voltage
40 +/-2
Welder Min CV Voltage
14 +/-2
12V Charge Voltage
14 +/-1
12V Boost Voltage
16 +/-1
24V Boost Voltage
29 +/-1
