9. Installing Software
98 PaX-i Plus / Insight Installation Manual
5. Check the equipment model (PaX-i Plus_Insight) and click Next
6. Make sure that all modalities are checked as the following. If the equipment does not
include the CEPH feature, uncheck the CEPH option and then click Next.
7. Make sure that “I2Pano or WidePano” is selected in the Pano sensor type selection
window and then click Next.
8. (Optional) Confirm that the WideCephis selected in CEPH sensor type selection
window and click Next.
9. Select COM2 for the default port number and click Next.
10. Select the language and click Next.
11. Select the 3
rd
party software in use and click Next. when EzDent-i is installed, select
SDK. Then, click Next to continue.
EzDent-i
12. Check the options according to the product specifications.
When the Auto Save is checked, the image data acquired saved
automatically.
13. Confirm that the following drivers are selected. For the first time installation, select all.
