Vatech PaX-i Plus

3. Before Installing the System
26 PaX-i Plus / Insight Installation Manual
3.3 Unpacking Boxes
 All packaging and Styrofoam used to ship this equipment is
recyclable.
 Return the packaging to VATECH representatives or dispose of
it in compliance with the legal regulations of your country.
3.3.1 Box No. 1 - Main Box
Component Size (mm / inch) Weight (kg / lbs)
 Column and Rotating
Unit Assembly
 Accessories and Parts
 PC System (Optional)
 Monitor (Optional)
1,710 (L) x 680 (W) x 1,100 (H) /
67" (L) x 27" (W) x 43" (H)
145 / 320
<Main Box>
