4. Installing the Equipment: Base Stand (Optional)
52 PaX-i Plus / Insight Installation Manual
4.6 Installing the CEPH Unit (Optional)
Never hold the areas of the collimator, sensor and tube head.
1. Now it is assumed that the CEPH box has already been opened.
2. Remove the plastic wrap covering the column unit and the tape for fixing the CEPH
cables by using a cutter.
3. Move and mount the CEPH unit on the Main Unit carefully, while observing the
insertion state of 4 studs.
