4. Installing the Equipment: Base Stand (Optional)
42 PaX-i Plus / Insight Installation Manual
4.2 Assembling the Base with the Column Unit
If the installation site is a concrete floor, go to the section 4.5 Fixing
the base (Optional) and do number 1 first, after that turn back 4.2
Assembling the Base with the Column Unit.
1. Hang the base unit onto two bolts temporarily as shown as shown as below.
An installer should hold the base unit to keep it from falling down.
