3. Before Installing the System
36 PaX-i Plus / Insight Installation Manual
Part
No.
Items Specification Figure QTY Comments
Confirmed
(OK?)
16
Silicon Cap White 18 Yes □ No □
17
Base Cap 1 4 Yes □ No □
Base Cap 2 3 Yes □ No □
18
Left Blank Intentionally
19
Left Blank Intentionally
20
Cable Tie 10 Yes □ No □
21
Frame
Grabber
System
Optic Cable 1
One additional
fiber optic
cable is
required when
Yes □ No □
IFC Card 1 Yes □ No □
22
Wall Bracket 2
1 Yes □ No □
Protractor 1 Yes □ No □
23
Wrench Bolt
M10 x 20
w/ Spring
4 Yes □ No □
24
Wrench Bolt
M10 x 25
w/ Spring and
Flat Washers
2 Yes □ No □
Wrench Bolt M10 x 25 2 Yes □ No □
25
Wrench Bolt
M8 x 45
w/ Spring and
Flat Washers
4 Yes □ No □
