4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight Installation Manual 57
Wooden Floor
Wood Screws
M12 x 70
(Part No. 34)
Hammer Drill
L = 200 mm
(7.9”)
Secure the base unit using the wood screws.
