4. Installing the Equipment: Base Stand (Optional)
62 PaX-i Plus / Insight Installation Manual
Leveling the Front and Back
1. Place the Spirit Level on the Vertical Frame, as shown in the following figure.
2. Adjust the screws until bubble of Spirit Level centers (level), by turning the front
and/or back screws clockwise or vice versa.
3. When the leveling is completed, make sure that all eight set screws touch the floor
by turning them clockwise if necessary.
4. Assemble the vertical top cover.
5. Assemble the case column front.
