5. Installing the Equipment: Wall Mount
72 PaX-i Plus / Insight Installation Manual
4. Put the set screws into the four holes and turn them clockwise with the hex wrench until
they touch the align plate.
T-shaped Hex
Wench
8 mm / 0.3”
Set Screw
M10 x 20
(Part No. 30)
5. Put the Spirit Level on the location as shown in the figure.
Leveling Right and Left
