Pax-i3D Smart(PHT-30LFO) Installation Manual
121
8 Installing Software
Selecting an Announcement Mode: Music or Beep (Optional)
When the need to select an announcement between music and beep arises, take following procedures.
Commands specications:
Command format: [SPM_MPOP_XXXX]
XXXX Imaging Modes Announcement mode Division
0000 CT/PANO Music Different for each mode
0001 CT/PANO Music The same for each mode
0002
(Default)
CT/PANO Beep The same for each mode
1.
Send the command in accordance with the command specication, as specied in the table above.
Here are some examples.
Default mode: 0002(b eep) for each imaging mode.
When the same music announcement is desired for CT and PANO imaging modality
.
Enter the command
[SPM_MPOP_0001]
in the command eld, followed by
Send
.
