Pax-i3D Smart(PHT-30LFO) Installation Manual
44
3 Before Installing the System
Part
No.
Items Specication Figure QTY Comments Conrmed (OK?)
15
SILICON
COVER
CHINREST 1 CT/PANO Yes
□
No
□
16
SILICON CAP Black 6 Yes
□
No
□
17
BASE CAP 3 Base Yes
□
No
□
18, 19
Left blank intentionally
20
CABLE TIE 10 Yes
□
No
□
21
FRAME
GRABBER
SYSTEM
Optic cable
(10m/32.8”)
1
(2)
If SC type is
installed, one
additional ber
optic cable is
required.
Yes
□
No
□
AG6 1
If PC is
supplied, card
is already
installed
Yes
□
No
□
22
COLUMN
BRACKET
1 Yes
□
No
□
23
WRENCH BOLT
M10 x 25
w/spring and
at washers
6
Assembling
Column To
Base
Yes
□
No
□
24
WRENCH BOLT M8 x 45 2 Yes
□
No
□
25
WRENCH BOLT
M8 x 20
w/spring
washer
4 Yes
□
No
□
FLAT WASHER 4 Yes
□
No
□
