Pax-i3D Smart(PHT-30LFO) Installation Manual
45
3 Before Installing the System
Part
No.
Items Specication Figure QTY Comments Conrmed (OK?)
26
TRUSS BOLT M5 x 8 3 Yes
□
No
□
27
TRUSS BOLT M4 x 8 10 Yes
□
No
□
28
FLAT HEAD
SCREW
3 x 6 2
CEPH
Yes
□
No
□
CEPH ARM
COVER
1 Yes
□
No
□
29
FLAT HEAD
SCREW
5 x 12 4 Yes
□
No
□
30
Left blank intentionally
31
PROTRACTOR 1 set CEPH Yes
□
No
□
32
Left blank intentionally
33
UP/DOWN
SWITCH
1
Optional
Yes
□
No
□
UP/DOWN
SWITCH
HOLDER
1 Yes
□
No
□
DOUBLE
SIDED
SITCKER
1 Yes
□
No
□
SCREWS M4 x 10 2 Yes
□
No
□
