Vatech PaX-i3D User Manual

PaX-i3D Green (PHT-60CFO) User Manual
136
12 Technical Specications
12 Technical Specications
12.1
Mechanical Specications
A. Image Magnication
Mode FDD (mm) FOD (mm) ODD (mm) Magnication
PANO 626.8 479.7 147.1 1.31 constant
CEPH 1,745 1,524 221 1.14 constant
CT 642.3 449.7 192.6 1.43 constant
FDD : Focal Spot to Detector Distance
FOD : Focal Spot to Object Distance
ODD: Object to Detector Distance (ODD: FDD - FOD)
Magnication: FDD / FOD
[PI3DG_130U_44A_en]User Guide.indd 136 2016-05-24 오후 4:19:14
