6 Acquiring PANO Images
Completing Patient Positioning
A. After conrming patient positioning and beam alignment, adjust the temple
supports to t snugly on both sides of the patient’s head by clicking the temple
support adjustment button.
B. Click the
READY
button after the patient has been properly positioned. No
X-ray will be emitted at this point.
C. Proceed to section
6.4 Initiating X-ray Exposure.
6.3.2 TMJ Open
There are two TMJ sub modes:
TMJ Open and TMJ Close
. Scan a TMJ Open
image first and then scan a TMJ Close image. To prepare and position the
patient, follow the process outlined below.
IMPORTANT
- Correct positioning is an important factor for image
capturing. Proper positioning will reduce the appearance
of the cervical spine in the reconstructed image.
- For a child with a large head circumference, Man/Woman
mode may be selected instead of Child.
Positioning the patient
A. Insert the Chin support into the Chinrest
receptacle on the equipment.
Disinfect the Chinrest using an
alcohol-based cleaning solution and
wipe away all residues with dry cloth
before proceeding any further.
B. Open the
Temple Supports
by clicking
the temple support adjustment button.
Lock / release knob
for bite block
Chin support
