PaX-i3D Green (PHT-60CFO) User Manual
157
Appendices
Guidance and manufacturer’s declaration - electromagnetic immunity
The PaX-i3D Green (Model: PHT-60CFO) is intended for use in the
electromagnetic environment specied below.
The customer or the user of the PaX-i3D Green (Model: PHT-60CFO)
should assure that it is used in such an environment.
Immunity
Test
IEC 60601-1-2
Test level
Compliance
level
Electromagnetic
environment -guidance
Electrostatic
discharge
(ESD) IEC
61000-4-2
±6kV Contact
±8kV air
±6kV Contact
±8kV air
Floors should be wood,
concrete, or ceramic tile.
If oors are covered with
synthetic material, the
relative humidity should
be at least 30%.
Electrical fast
transient/
burst IEC
61000-4-4
±2kV for power
Supply lines
± 1kV for input/
output lines
±2kV for power
Supply lines
± 1kV for
input/output
lines
Main power quality
should be that of a
typical commercial or
hospital environment.
Surge IEC
61000-4-5
±1 kV line(s) to
line(s)
±2 kV line(s) to
earth
±1 kV line(s) to
line(s)
±2 kV line(s) to
earth
Main power quality
should be that of a
typical commercial or
hospital environment.
Voltage
dips, short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-
4-11
<5% UT
(>95% dip in
UT)
for 0.5cycle
40% UT
(60% dip in UT)
for 5 cycle
70% UT
(30% dip in UT)
for 25 cycle
<5% UT
(<95% dip in
UT)
for 5 s
<5% UT
(>95% dip in
UT)
for 0.5cycle
40% UT
(60% dip in UT)
for 5 cycle
70% UT
(30% dip in UT)
for 25 cycle
<5% UT
(<95% dip in
UT)
for 5 s
Main Main power quality
should be that of a
typical commercial or
hospital environment.
If the user of the PaX-
i3D Green (Model: PHT-
60CFO) image intensier
requires continued
operation during main
power interruptions, it is
recommended that the
PaX-i3D Green (Model:
PHT-60CFO) image
intensier be powered
from an uninterruptible
power supply or a
battery.
Power
frequency
(50/60Hz)
magnetic
eld IEC
61000-4-8
3 A/m 3 A/m Power frequency
magnetic elds should
be at levels characteristic
of a typical location in
a typical commercial or
hospital environment.
NOTE UT is the a.c. main voltage prior to application of the test level.
