Initial Setup Of The Console Using Workflow Wizard Setup>Automatic Events>Device Tasks
51
Setup>Automatic Events>Device Tasks
This screen lists the device tasks currently configured for the console, and it also allows you
to add, edit, or delete these tasks.
Screen Column Descriptions
Ev ID - Identifier automatically assigned to an event by the console.
Time/Event - Event that triggers the task (for example, "Overfill Alarm").
Device/Connection Mode
- Label of the device that is involved in performing the function
(usually this is a relay, such as "Relay 1").
Adding or Editing A Task
1. Do the following:
• If editing a task, select a task record to modify (a checkmark appears next to the entry),
then select Actions>Edit Task.
• If adding a task, select
Actions>Add Task.
2. Touch the fields below to enter or edit the appropriate
information:
• Device - Select the relay from the list of available relays
on your console (you can also select other devices).
• Trigger - Select a trigger from the list of available trig-
gers (Events). The triggers that you see depend on your
configuration. For example, a console alarm can be a trig-
ger for a device task.
3. Touch to save your settings.
Deleting A Task
1. Select the task record entry that you want to delete (a
checkmark appears next to the entry).
2. Touch Actions then Delete Task.
3. Touch to save your settings.
