Introduction VaporTEK Pump Characteristics
13
Figure 3. VaporTEK Pump Dimensions
VaporTEK Pump Specifications
Function Description
Flow medium Gasoline vapor
Flame Arrestors Type: Ex IIA; Inlet & Outlet Ports
Mounting Four M6 X 1 Mounting Boss (Either side of the pump)
Motor Type Synchronous BLDC (Brushless DC) Motor
Voltage (Single Phase) 230 VAC (±10%)
Frequency 50/60 Hz
Watts 250W
Motor Speed 2500 rpm max.
Maximum flow rate Up to 120 lpm
Noise Level 59 dB (A)
Flame Arrester (1)
Outlet Port G 1/4”
Flame
A
rresters (2)
Inlet Ports G 1/4” (2)
Mounting Boss (4)
Both Sides (M6 x 1)
Flow Direction to UST
W = 140 mm
H = 235 mm
L = 245 mm
Sensor Cable
Motor Cable
M22 x 1.5,6g Hex
Cable Retainer (2)
65 mm
65 mm
