Veeder-Root VaporTEK User Manual

Introduction VaporTEK Valve Adapter Board (Optional)
17
Figure 7. VaporTEK Valve Adapter Board Connected To The VaporTEK-3 Controller board
VEEDER-ROOT
VTEK3-EPV-
ADAPTER
141085646
A B 0V 5Vout
X2
X1
F1 F3
SIDE B
SIDE A
VaporTEK
Valve Adapter Board
315mA
To The Existing
24VDC Power Supply
315mA
EPV B EPV B
VEEDER-ROOT
VAPORTEK-CONTROLLER
900890-001
Rev.C P/N 141 031 916 S/N 0000586 DATE 49/2016 RoHS Compliant
PE
F1
PE
L N PE M1 M2
+ - AB SB AA SA EPV VALVE
MOTOR
POWER
MOTOR
SIGNAL
J3
X7
X6
X8
PROGRAM
J1
J2
X3X2
X1
X4
BR1
IC5
RS422
PE GND +24V
Duncansville,PA.16
Type: EPV10
SIRA 12ATEX6058X -40°
Valve: II 1/2G c T3
Solenoid: II 2G Ex MB
EPV B
EPV A
EPV B
