Veeder-Root VaporTEK - Liquid Pulse Signal Input Wiring; VaporTEK Liquid Pulse Signal Diagram

Wiring Schematics VaporTEK Wiring
29
Figure 16. VaporTEK System - Liquid Pulse Signal Input
VEEDER-ROOT
VAPORTEK-CONTROLLER
900890-001
Rev.C P/N 141 031 916 S/N 0000586 DATE 49/2016 RoHS Compliant
PE
F1
PE
L N PE M1 M2
+ - AB SB AA SA EPV VALVE
MOTOR
POWER
MOTOR
SIGNAL
J3
V6
V3 V8
V1
X7
X6
X8
PROGRAM
J1
J2
X3X2
X1
X4
BR1
IC5
RS422
UNSAFE AREA
UNSAFE AREA
SAFE AREA
O/T - GND (OFF)
TEMP. >120°C
O/T - GND (ON)
TEMP. <120°C
FB1 Service Terminal
Motor Power
Cable
M4 - W (PWM)
M2 - V (PWM)
M1 - U (PWM)
M3 - VCC (+5V)
Motor Signal
Cable
S4 - GND
S3 - H3
S2 - H2
S1 - H1
S5 - O/T
L1 N
MAIN
230V
L1 N PE
M1 M2
F6
F1
F8
F3
Home
7
END
1
•
SHIFT SPACE ENTER
INS
0
—
+
2
PgDn
3
4 5 6
PgUp
9 8
F9
F4
F10
F5
F7
F2 START
VTEK3-
CTRL
X3
26-Pin Flat
Ribbon Cable
579292-001
VaporTEK-3 Pulse
Interface Adapter
141 086 646
8-24V DC
Pulse Side A
PULS
Power Supply
100W
140 810 856
24V
DC
OK
LN
++
++
Pulse Side B
To the encoder lines
of target dispenser
GND
GND
P4A
P3A
P2A
P1A
GND
GND
P4B
P3B
P2B
P1B
