VaporTEK Calibration Simulation with FB1 Terminal
50
5. Set the A/L Ratio rate:
6. Wait while the auto-calibration is calibrating through 15 points:
The auto calibration procedure will complete at test point 1.
After the auto-calibration has been accomplished the result of calibration needs to be verified using dry simula-
tion. Follow the steps 1- 6 of the Simulation section and verify the A/L – Ratio which is shown as “Rate”:
The Rate as displayed on the FB1 Terminal shall be within the legislated range established by local regulation.
Simulation with FB1 Terminal
1. Press the START green button on the FB1 Terminal until the below screen appears. Press the keys as shown:
Select Side
Side 1 (1)
Side 2 (2)
1 2
or
**Adjustment**
Rate 100 %
Offset 001
Change with F2
Auto Calibration
Side: 1
Test point: 15
Vap: 048.00 l/min
VAPOR CONTROLLER
Rate 99.5 %
Set 40.0 l/min
Cur 39.8 l/min
*** SERVICE ***
SAL – pump (1)
S&B – pump (2)
GIL – pump (3)
To Next Page
