Installation VaporTEK Pump
20
Figure 8. VaporTEK Pump Installation Orientations
Preferred Pump Installation
Orientation
Fins Down
Acceptable Pump Installations
Orientation
Fins Up Motor Facing
Incorrect Pump Installation
Motor On Top Motor Down
