17
Operations & Maintenance Manual: Introduction
0900‑5005 REV‑00
ICON FUNCTION
Next—While viewing B‑mode images on the Results screen, advance to the next scan
plane or angle.
Brightness—Adjust the brightness of the touchscreen. The icon shows the current
setting.
Volume—Adjust the volume of sounds played through the console’s speaker. The icon
shows the current setting.
Increase—Turn up the brightness or volume.
Decrease—Turn down the brightness or volume.
Mute—Turn the speaker on or off.
Play—While viewing the onboard tutorial, start or resume playback.
Pause—While viewing the onboard tutorial, pause playback.
Previous—While viewing the onboard tutorial, return to the previous frame.
Next—While viewing the onboard tutorial, advance to the next frame.
On the Results screen, expand the history list of scans taken during the current exam.
On the Results screen, close the history list of scans taken during the current exam.
Close the Barcode window or a warning dialog box.
