Verathon BladderScan i10 User Manual

32
0900‑5005 REV‑00
PROCEDURE 3. CONFIGURE EXAM SETTINGS
You may configure these exam settings:
• Display of B‑Mode images
• Live B‑mode aiming
• Time‑out interval for the live B‑mode aiming feature
• Bladder outline on B‑mode images
• Display of exam results in barcode format
• Assignment of an automatically generated patient ID number at the beginning of each exam
1. On the Home screen, tap Settings, and then tap Exam.
2. If a keypad appears, key in the PIN for Settings, and then tap Enter.
3. On the Exam tab, tap the field to update, and then if applicable, select or type the new value:
• Enable Live B‑Mode Aiming—Activates a real‑time, B‑mode ultrasound preview of the bladder
before the scan to provide aiming assistance.
• Inactivity Timeout—Defines the amount of time that live B‑mode aiming is active. Once the timeout
period has been reached, the system returns to the Home screen. This setting is only visible if live
B‑mode aiming is enabled.
• Enable B‑Mode Plane Images—Allows the display of B‑mode images in active and saved exams.
• Enable On‑Screen Barcode—Displays a patient’s exam results as a barcode, in addition to the
readable numbers the system normally displays.
• Enable BladderTraq™ Outline—On B‑mode images, displays a green outline around the detected
edges of the bladder.
• Assign Patient ID Automatically—Automatically generates a new patient ID for each exam. You
can replace this ID at the beginning of an exam, as described in the section “Input Patient Information
or Operator ID (Optional)” on page38.
4. When you are done, tap Back. This saves your settings and returns the console to the Home screen.
